Introduction: Introducing the All-New ZLM777-2VL Series
The ZLM777-2VL Lawn Mower revolutionizes grass collection with nearly 100% bag filling efficiency—solving one of the most common frustrations in lawn maintenance. Designed for both residential and small commercial users, this mower delivers not only clean cuts, but also unmatched grass discharge performance.
Ideal for landscaping contractors, golf course maintenance teams, and suburban homeowners who demand high performance and efficiency.
-Product Name: ZLM777-2VL Lawn Mower
-Voltage: 40 V
-Motor Speed: 2800 rpm
-Rated Power: 900W MAX
-Battery Capacity: Standard 5.0 Ah
-Grass Box Capacity: 50L
Blade Design: Featuring a rear-curved chamfer on the blade head that forms a dual-edge configuration: one side is a conventional sharp cutting edge, while the other is an upward-curved chamfer (T-shaped profile).
Air Duct Design: A unique upward airflow duct that channels cut clippings to the end of the grass box, ensuring even and complete filling from start to finish.
Height Adjustment: Multiple cutting height settings to suit various lawn conditions.
Safety & Ease of Use: Equipped with overload protection, dual-start switches, and a lightweight, foldable handle for easy operation and storage.
Many conventional lawn mowers only manage to fill half the grass box, resulting in frequent stops for manual clearance—thereby increasing maintenance time and labor. The ZLM770-2VL’s innovative design offers the following benefits:
Efficient Grass Collection: Supports continuous operation without the need for repeated emptying.
Time Savings: Enhances operational flow and reduces maintenance interruptions.
Enhanced Lawn Aesthetics:Ensures professional-grade lawn care with consistently neat results.
Through in-depth discussions with Manager Deng and an exclusive teardown of the mower, we discovered two primary innovations behind our exceptional grass collection performance.
1. Blade Head and Chamfer Design
Manager Deng explains that the ZLM770-2VL employs a dual-edge blade design:
One side is a traditional, sharp cutting edge for precise trimming. The opposite side features an upward-curved chamfer (T-shaped profile), which uses centrifugal force to immediately fling freshly cut grass into the guide duct.
This design significantly enhances the efficiency of clippings transfer, setting the stage for the next phase of collection.
2. Unique Upward Air Duct Design
The specially engineered duct generates a robust, orderly airflow that directs cut clippings upward. The clippings are then guided toward the far end of the grass box, progressively building up and filling the bag completely.
Compared to conventional systems, this design enables a nearly 100% full collection, eliminating the need for multiple stops to empty the bag.
Through the fan blades positioned above the blade on the coaxial motor, air is drawn in from the bottom. The resulting air pressure carries the grass clippings into the airflow duct, effectively dispersing them and making collection significantly easier.
Turning Innovation into User Benefits — Our technical breakthroughs convert directly into tangible advantages for the user:
Full Grass Bag, Hassle-Free Maintenance: The high-efficiency grass collection system minimizes interruptions and reduces the need for constant bag emptying.
User-Friendly Operation: A lightweight design, smooth height adjustment, and easy-to-use controls offer an exceptionally pleasant operating experience.
Eco-Friendly & Quiet Performance: Compared to traditional mowers, our design delivers lower noise levels and enhanced energy efficiency.
In practical applications, numerous customers have reported remarkable improvements in grass collection efficiency, overall mowing performance, and maintenance ease.
The ZLM770-2VL Lawn Mower is not just a cutting tool—it’s a revolutionary solution for comprehensive lawn care. With its innovative blade head with an upward-curved chamfer and unique upward air duct, the ZLM770-2VL ensures a fully loaded grass bag in every operation, boosting your efficiency and delivering a superior mowing experience.
Experience the future of lawn care today. To learn more or schedule a live demonstration, please visit our website or contact our sales team directly.
