LCD777-10LSC
Liangye
| Quantity: | |
|---|---|
LIANGYE 20V Battery Cordless Hammer Drill is designed for the professional carpenter, remodeler, and general contractors who rely on high-performing and durable tools. It is engineered to provide reliable operation and a long service life under normal operating conditions.
Equipped with the ANTI-ROTATION System that senses the rotational motion of the tool and shuts it down if the motion is excessive.
This tool has a clutch with adjustable torque for driving and removing a wide array of fastener shapes and sizes. The numbers on the mode selection collar are used to set a torque range for screw driving.
The higher the number on the collar, the higher the torque will be.
KEY FEATURES | |
Model NO. | LCD777-10LSC |
Voltage | 20V[Li-ion] |
No-Load Speed | 0-550 RPM / 0-2000 RPM 0-700 RPM / 0-2500 RPM |
Impact Rate | 0-8800 RPM / 0-32000 RPM 0-11200 RPM / 0-40000 RPM |
Torque Setting | 20+3 [Function] |
Max Torque | 150N.m |
Chuck | 1.5-13 mm metal chuck with self-lock system |
1. 20V Battery offers sufficient power for a wide range of impact drilling applications.
2. The LED work light is activated when the trigger switch is depressed, and will automatically turn off 10 seconds after the trigger switch is released. If the trigger switch remains depressed, the LED work light will remain on.
3. Integrated Bell hook for easy storage.
4. Electric brake to stop drill after trigger is released.
Recommendations for Hammer Drilling:
• When drilling, always apply pressure in a straight line with the bit, but do not push hard enough to stall the motor or deflect the bit.
• Too much force will cause slower drilling speeds, overheating, and a lower drilling rate.
• A smooth even flow of material indicates the proper drilling rate.
• Drill straight, keeping the bit at a right angle to the work. Do not exert side pressure on the bit when drilling as this will cause clogging of the bit flutes and a slower drilling speed.
• When drilling deep holes, if the hammer speed starts to drop off, pull the bit partially out of the hole with tool still running to help clear debris from the hole.
